Wooden Acoustic Wall Panel

Wooden Acoustic Wall Panel Manufacturer for Commercial & Architectural Projects

Our Wooden Acoustic Wall Panels combine a wood-based decorative surface with an acoustic backing layer to reduce sound reflections and control reverberation in interior spaces.

From standard panels to custom CNC patterns and project-specific dimensions, we can manufacture panels based on drawings, samples or agreed technical specifications.

First 12 Last

Parameter

Name	Acoustic Panel
Size	2400/2700/3000*21mm or customized
Basic Material	100% Polyester fiber board +mdf slat/wpc slats+ wood veneer/pvc film
Surface	Technology wood veneer/Natural wood veneer/pvc film
Slat Width	25mm/27mm
Slat Gap	15mm/13mm
Density	9mm Base panel-1400gsm,12mm MDF Slats-720gsm
Customization	OEM/ODM
Keywords	Acoustic panel
Application	Hotel,villa,home,office,cinema,shop or etc

Product Range & Construction

Our wooden acoustic wall panels are available in different material and surface combinations to meet architectural, acoustic and budget requirements.

MDF Wood Slat Acoustic Panels

MDF slats are combined with PET acoustic backing to provide a stable panel construction for commercial and interior projects. Slat width, spacing and surface finish can be adjusted according to the design.

WPC Wood Slat Acoustic Panels

WPC slats can be specified where the project requires an alternative to conventional MDF-based construction. Available surface treatments depend on the selected product configuration.

Veneered Acoustic Panels

Natural or engineered wood veneer can be applied to the slat surface to achieve the required architectural appearance.

PVC-Finished Acoustic Panels

PVC film provides an alternative surface finish where consistent color, pattern or easier surface maintenance is required.

Wood Species & Surface Finishes

Engineered Veneer：Engineered veneer provides a more controlled grain pattern and can be used when consistent appearance is required across larger quantities.

Solid Wood：Selected solid wood species can be processed for projects requiring a genuine timber surface.

How to Select the Right Wooden Acoustic Wall Panel

Identify the Acoustic Problem
Determine whether the project needs to reduce reverberation, control reflected sound or improve speech clarity.

Evaluate the Room
Room volume, wall area, ceiling height, occupancy and existing acoustic treatment all affect the amount and location of acoustic treatment required.

Select the Panel Construction
Consider the combination of:
Wood surface
Slat or groove structure
Acoustic backing
Panel thickness
Open area
Air cavity

Check the Available Installation Space
If a wall cavity is available, the mounting configuration can be designed accordingly. If the panel must be installed directly against the wall, a different acoustic construction may be more appropriate.

Select the Wood Finish
Choose natural veneer, engineered veneer, solid wood or another finish according to the architectural design, project quantity, color requirements and budget.

Confirm Fire and Environmental Requirements
For commercial, hospitality, education and public projects, confirm the required fire classification, MDF emission level, VOC requirements and other local regulations before finalizing the material.

Confirm Installation Method
The panel should be specified together with its fixing method. Screw fixing, adhesive, clips, battens or other systems may be used depending on the wall structure and panel construction.

Manufacturing Capability

CNC Machining for Project-Specific Designs

Our production process supports CNC machining for slats, grooves, perforations, edges and custom patterns. Drawings, CAD files and approved samples can be used as production references.

Flexible Panel Construction

Panel dimensions, slat width, slat spacing, groove details, backing and surface finish can be adjusted according to the approved project specification and production capability.

Project-Based Production

For architectural projects, we can work from drawings and samples through technical review, sample development, approval and mass production to maintain consistency with the approved construction.

Manufacturing Process

01/

Raw Material Inspection
Wood, MDF, WPC, veneer and acoustic backing materials are checked according to the specified material requirements before production.

02/

Veneer & Surface Finishing
For veneered products, the selected veneer is applied to the substrate and processed through sanding and finishing.

03/

Cutting & Preparation
Materials are cut and prepared according to the required panel dimensions.

04/

CNC Machining
Slats, grooves, perforations, edges and custom patterns are machined according to production drawings.

05/

Acoustic Backing Assembly
The specified PET acoustic backing is assembled with the wooden panel structure according to the approved construction.

06/

Dimensional Inspection
Finished panels are checked for panel dimensions, thickness, slat width, spacing, groove dimensions and other order-specific requirements.

07/

Surface Inspection
Veneer matching, color consistency, scratches, glue marks, coating quality and edge condition are inspected before packing.

08/

Final Packing
Approved panels are surface-protected, labeled and packed according to the product requirements and shipping method.

Quality Control

Incoming Material Control
Depending on the material, incoming inspection may cover:
Wood species
Moisture
MDF / plywood thickness
Density
Surface quality
Acoustic backing thickness and density

Machining Control
Production dimensions are checked for:
Panel length and width
Panel thickness
Slat width
Slat spacing
Groove width
Groove depth
Perforation dimensions

Studio Acoustic Foam Panels High Density

Acoustic Foam Soundproof Panels High Density

Surface Quality Control
Finished surfaces are checked for:
Color consistency
Grain matching
Surface scratches
Coating quality
Edge condition
Glue marks

Acoustic Testing
Where required, products can be tested for:
Sound absorption coefficient
NRC
αw
Frequency response

Fire & Environmental Testing
Available certifications or test reports may include:
[ASTM E84]
[EN 13501-1]
[E0 / E1]
[CARB P2]
[TSCA Title VI]
[FSC]
[REACH]
[Other Actual Certifications]

OEM & Custom Manufacturing

Custom Dimensions

Panel length, width and thickness can be adjusted to the project requirements, subject to production capability.

Custom CNC Patterns

For architectural projects, CNC machining can be used for special patterns, perforations, curved elements and other designed surfaces.

Custom Slat & Groove Design

The following can be customized:
Slat width
Slat spacing
Groove width
Groove depth
Pattern
Panel layout

Custom Wood & Finish

Customers can specify:
Wood species
Veneer type
Color
Stain
Surface coating
Grain direction

Project Development Process

Project Specification

Review drawings, panel dimensions, wood species, surface finish, acoustic requirements, quantity and applicable standards.

Technical Review

Our production team checks the proposed construction, machining details, material availability and installation requirements before sampling.

Sample Development

A sample is produced to confirm the panel structure, dimensions, wood finish, color and surface details.

Sample Approval

The approved sample and technical drawings become the reference for mass production.

Mass Production

Production follows the approved specifications, with dimensional, machining and surface inspections carried out during processing.

Final Inspection & Delivery

Finished panels are checked against the approved requirements before protective packing and shipment.

Packaging

Wooden acoustic panels require protection against impact, scratches and moisture during handling and transportation.

Depending on the product, export packing can include:
Individual surface protection
Corner protection
Carton packing
Pallet packing
Moisture protection
Customized labels
Shipping marks

FAQ

Q: Are wooden acoustic wall panels soundproofing panels?

A: No. They are primarily sound-absorbing products used to reduce reflected sound and reverberation inside a room. Sound insulation between rooms depends on the complete wall, ceiling or partition construction.

Q: What affects the acoustic performance of a wooden acoustic panel?

A: The main factors include PET backing thickness and density, panel construction, slat width and spacing, open area, panel thickness, air cavity and installation method.

Q: Does an air gap affect acoustic performance?

A: Yes. The mounting condition can affect sound absorption. Acoustic test results should therefore be reviewed together with the tested installation configuration.

Q: What is NRC?

A: NRC, or Noise Reduction Coefficient, is a commonly used rating related to sound absorption. The value should always be considered together with the test method and product construction.

Q: Can you customize panel dimensions?

A: Yes. Panel dimensions can be customized according to drawings and production requirements.

Q: Can you customize slat width and spacing?

A: Yes. Slat width, spacing, groove dimensions and CNC details can be adjusted for project-specific designs.

Q: Can you match a specific wood color?

A: For available veneer and finishing options, we can work from an approved physical sample or color reference.

Q: Can you manufacture from drawings?

A: Yes. CAD files, technical drawings, specifications and physical samples can be used as references for custom production.

Q: Can I receive a sample before placing a bulk order?

A: Yes. Samples can be developed to confirm material, construction, dimensions, finish and color before mass production.

Q: Can you provide acoustic test reports?

A: Available acoustic test documentation depends on the selected panel construction. Where applicable, sound absorption data, NRC or other specified test reports can be provided.

Q: Can you provide fire or environmental documentation?

A: Documentation depends on the exact materials and panel construction. Applicable reports or certifications can be confirmed during the technical review.

Q: What information is needed for a quotation?

A: Please provide the required panel dimensions, construction or material, wood species or finish, acoustic backing, estimated quantity, installation condition and any required acoustic, fire or environmental standards.

Q: How are the panels packed for export?

A: Panels are protected against surface damage and packed according to the panel construction, dimensions, shipping method and container loading requirements.

Q: How are the panels packed for export?

A: Panels are protected against surface damage and packed according to the product construction, shipping method and container loading requirements.

We're known as one of the most experienced wooden acoustic wall panel manufacturers in China. With a professional production team, we offer a wide range of products with superior quality. If you're going to wholesale bulk high quality wooden acoustic wall panel, welcome to get free sample from our factory.
