MDF Acoustic Wall Panel

MDF Acoustic Wall Panel Manufacturer for Commercial & Architectural Projects

We manufacture MDF acoustic wall panels for commercial interiors, hospitality, education, healthcare, residential and other architectural projects. Panels combine precision-machined MDF with PET acoustic backing to reduce room reverberation while providing a wood-based decorative finish.

Available in slatted, grooved and perforated constructions, with custom dimensions, finishes, MDF grades and acoustic backing options for project requirements.

Product Specifications

Specification	Standard Options
Panel Sizes	2400 × 600 mm, 2700 × 600 mm, 3000 × 600 mm, 1200 × 600 mm
Panel Thickness	12 mm, 15 mm, 18 mm; custom thickness available
MDF Density	750–800 kg/m³
PET Acoustic Backing	9–12 mm
MDF Options	Standard MDF, moisture-resistant MDF, fire-retardant MDF
Formaldehyde Emission	E0, E1, CARB Phase 2 options
Surface Finishes	Natural veneer, engineered veneer, melamine, HPL, paint, UV lacquer
Fire Performance	Fire-rated constructions available according to specified requirements
Weight	Approx. 8.5–11.5 kg/m², depending on construction and thickness
Customization	Size, slot width, slot spacing, perforation, finish and backing

Panel Structure & Material Construction

Our acoustic wall panels are built from several functional layers, with each layer selected according to the required appearance, acoustic performance and installation conditions.

Decorative Surface

Natural wood veneer, engineered veneer, melamine, HPL, paint or UV lacquer can be applied according to the project finish schedule.

MDF Core

High-density MDF provides the structural base for machining and surface finishing. Standard, moisture-resistant and fire-retardant MDF options are available for different project conditions.

Acoustic Backing

The rear side can be fitted with black acoustic fleece or recycled PET acoustic felt, typically 9–12 mm thick. The backing works with the machined MDF surface and installation cavity to absorb sound energy.

Acoustic Performance

Acoustic performance depends on the panel construction, slot or perforation pattern, backing material, air cavity and installation method.

Surface Finishes & Design Options

Natural Wood Veneer

Oak, Walnut, Ash, Teak, Ebony, Maple and Beech are available for projects requiring a natural timber appearance.

Engineered Veneer

Provides more consistent grain and color across larger quantities and multi-room projects.

Melamine & HPL

Available in wood grains, solid colors and other decorative finishes where scratch resistance and easier maintenance are required.

Paint & UV Lacquer

Custom colors can be matched to specified RAL or Pantone references, subject to sample approval.

PET Felt

Black, dark grey, light grey, off-white and charcoal are standard options, with additional colors available for selected projects.

Applications by Project Type

Designed for commercial, institutional, and high-end residential interiors:

Commercial Offices & Boardrooms: Reduces ambient echo in open-plan spaces, improving conference call clarity and speech privacy.

Hotels & Hospitality: Creates warm, luxurious feature walls in lobbies, corridors, and private dining rooms while maintaining acoustic comfort.

Education & Healthcare: Improves acoustic comfort in lecture halls, libraries, and hospital reception zones to minimize noise fatigue.

Recording Studios & Home Theaters: Balances room reflections for accurate sound monitoring and immersive listening environments.

Decorative MDF Acoustic Panel Soundproof

How to Select the Right Panel

Acoustic Requirement
Determine whether the project primarily requires reverberation control, speech clarity or broader sound absorption. Panel construction and backing should be selected accordingly.

Panel Construction
Slatted, grooved and perforated designs provide different acoustic and visual characteristics. The slot or perforation pattern should be matched to the required acoustic build-up.

Backing & Air Gap

PET thickness, additional acoustic material and rear air cavity can affect overall absorption. For projects with defined acoustic targets, the complete installation build-up should be considered.

Environmental Conditions

Standard MDF is intended for controlled interior environments. Moisture-resistant MDF can be specified for areas with higher humidity.

Fire Requirements

For public and commercial projects, the required fire classification should be confirmed at the product-construction level before ordering.

Manufacturing Process

Material Inspection
MDF boards, veneers, decorative surfaces and PET backing are checked against production requirements before processing.

CNC Machining
Automated cutting, grooving, slitting and perforation control panel dimensions, slot spacing and machining depth.

Surface Finishing
Veneer, melamine, HPL, paint or other specified finishes are applied according to the approved sample and production specification.

Acoustic Backing
PET felt or acoustic fleece is bonded to the rear of the machined panel using the specified bonding process.

Final Inspection
Finished panels are checked for dimensions, surface appearance, edge condition, machining consistency and backing adhesion before packing.

OEM & Custom Manufacturing

We supply customized acoustic panels for distributors, brand owners, interior contractors and project-based buyers.

Customization can include:
Panel dimensions and thickness
Slat width and slot spacing
Groove or perforation patterns
MDF grade
PET backing thickness and color
Veneer and decorative finish
RAL or Pantone color matching
Private-label packaging
Installation and product documentation

Manufacturing Capability

With a 20,000 m² production base in Shandong and more than 26 years of experience in acoustic materials, Qingdao Greenwall Decor integrates product development, manufacturing and quality control in-house.

For MDF acoustic wall panels, our production capability covers CNC cutting and machining, surface finishing, acoustic backing assembly and final inspection.

Frequently Asked Questions

Q: Can MDF acoustic wall panels be used in humid areas?

A: Standard MDF is intended for controlled indoor environments. Moisture-resistant MDF can be specified for projects with higher humidity, together with an appropriate surface finish.

Q: Can you provide acoustic test reports?

A: Acoustic test reports can be provided for applicable panel constructions. Because acoustic results depend on the complete panel build-up and installation condition, the test configuration should be confirmed against the project specification.

Q: Can the panel size and slot pattern be customized?

A: Yes. Panel dimensions, thickness, slot width, spacing, groove pattern and perforation can be customized according to drawings or project requirements.

Q: Do you offer custom veneer and color matching?

A: Yes. Natural and engineered veneers, melamine, HPL and painted finishes are available. Custom colors can be matched against approved RAL or Pantone references where applicable.

Q: What is the typical production lead time?

A: For standard configurations, production normally takes around 12–15 working days after order confirmation and sample approval. Customized projects may require additional time depending on materials, finish and quantity.

Q: How are the panels packed for export?

A: Panels are protected with surface interlayers, edge protection and reinforced export packaging before being loaded on wooden pallets. Packaging can be adapted to container loading and project shipping requirements.

We're known as one of the most experienced MDF acoustic wall panel manufacturers in China. With a professional production team, we offer a wide range of products with superior quality. If you're going to wholesale bulk high quality MDF acoustic wall panel, welcome to get free sample from our factory.
